SMTEK is a research-based company with in-depth knowledge and experience with color-changing materials. We focus on developing products to satisfy our customers’ demands to reduce damage to people from exposure to hazardous chemicals. We contribute to pioneering in new markets and expanding existing markets through new product development that allows workers to more effectively detect leakage of hazardous chemicals. Our main products are chemical leak detection tape, flange band, and flange guard. In this post, we will introduce safety spray shield.
1. Use of safety spray shield
Safety spray shields are important industrial safety products designed to safely dissipate high pressure spray of hazardous chemicals such as acids, alkalis, solvents, oils and are used to prevent worker injuries and equipment damage. In addition to preventing chemical spraying, our safety spray shields can be used to visually identify the leak site at an early stage using our various leak detection tapes. We offer two types of safety spray shield: flange cover (flange guard) and flange band.
2. Flange cover (flange guard) specification
The size of the flange cover is manufactured according to flange standards (ANSI, DIN, JIS), and the product specifications are as follows.
[Specification]
- Material: Clear PVC film + Chemical resistant fabric + PP rope + PTFE sewing thread
- Operating temperature: RT (Max. 80 oC)
※ Use with a leak detection tape
[Properties of Chemical Resistant Fabric]
[Leak detection tape & detectable chemicals]
[Feature of flange cover]
Our flange covers are suitable for applications requiring simultaneous detection of splashes and chemical leaks. The main materials of the flange covers are clear PVC film and yellow chemical-resistant fabric, and they are secured to the flange using Velcro and PP rope. They can be used in conjunction with our various leak detection tapes listed above. For the detection of acid, alkali, and organic solvent leaks, the covers can be supplied with the tape already attached.
3. Flange band specification
The length of the flange band is manufactured according to the flange standards (ANSI, DIN, JIS) and pressure rating, and it is available in widths of 30, 40, and 50 mm. The flange band can be easily applied to a flange using Velcro fasteners sewn with Teflon thread at both ends.
[Specification]
- Use: spray shield + leak detection
- Material: Fluorinated film + Chemical detection layer
- Detectable chemicals: Acids & alkalis
- Operating temperature: RT (Max. 80 oC)
[Detectable chemicals]
https://www.youtube.com/watch?v=y4yqvBzRIEk
https://www.youtube.com/watch?v=AT3fgCy05DY
https://www.youtube.com/watch?v=x2efsLnPSSc
[Feature of flange band]
Our flange band is a patented product suitable for simultaneously preventing scattering and detecting chemical leaks. It features easy attachment/detachment and maintenance, as well as excellent chemical and physical properties.
The fluorinated film of the flange band exhibits excellent weather and chemical resistance, and the leak detection layer is prepared using our patented technology.
.
Flange band (FBFT): Water Resistance Test
Flange band (FBFT): Accelerated Weathering Test
4. Sales references
a) Customers
- Domestic sales
Petrochemical/Fine Chemical Companies, Power Plants, POSCO
Semiconductor Specialty Gas/Precursor manufacturing Companies
Samsung, LG, SK Hynix, Lotte, Hyundai Motors, etc.
Pipe & Seal Manufacturing and Installation Companies
- Oversee sales
China, Japan, Singapore, Taiwan, EU etc.
b) Applications
- Chemical resistant pumps, valves, flanges, reactors, chemical storage tanks, etc.
The flange cover and flange band manufactured by our company are supplied to many industries handling hazardous chemicals, including semiconductor, display, power plants, and chemical companies, and etc.
Please contact us if you require inquiries or quotations regarding the above safety spray shields and leak detection tapes.
